Worldwide Aersosol Characterization

At TROPOS a small sophisticated lidar system called Polly has been developed and permanently improved  to perform automated stand-alone lidar measurements in remote areas and to fulfill latest requirements of aerosol profiling in scientific networks, e.g., EARLINET. Several Polly systems have been setup and successfully operated worldwide with international partners for field campaigns and scientific lidar networks. The data from the automated lidars is directly transferred to a server and quicklooks and level 1aerosol products are provided in near-real time at the PollyNet Website. In this way, a network of Polly systems with homogenous data analysis structure called PollyNET was established by TROPOS and the collaborating institutes.

From the lidar observations, aerosol can be characterized by means of vertically resolved optical properties and by source analysis. Heterogeneous freezing processes are investigated in dependence on cloud top temperature. The main objective of the network is to obtain aerosol and cloud climatologies at key region for the Earth’s climate. Thus, PollyNET is considered as a scientific contribution to the GAW Lidar Observation Network. But PollyNET can also act as a valuable tool to monitor hazardous plumes ,e.g. from volcanic eruptions or for validation measurements of satellites. Furthermore, the lidar observations are also used for numerous scientific studies and exploitation of new synergy methodologies by combining different instruments, like sun photometer and lidar or lidar and radar. In future, we aim to provide the PollyNET data also for data assimilation purposes in aerosol transport models.



Baars, H. et al., An overview of the first decade of PollyNET: an emerging network of automated Raman-polarization lidars for continuous aerosol profiling, Atmos. Chem. Phys., 16, 5111-5137.


Engelmann, R. et al.: The automated multiwavelength Raman polarization and water-vapor lidar PollyXT: the neXT generation, Atmos. Meas. Tech., 9, 1767-1784.

Althausen, D. et al. (2009): Portable Raman Lidar Polly(XT) for automated profiling of aerosol backscatter, extinction, and depolarization. Journal of Atmospheric and Oceanic Technology, 26(11), 2366-2378.
